AIR-VAC M-25 AIR CLEANER

2,500 FT3/MIN. | A HEALTHY SOLUTION FOR CLEAN AIR

The Air-Vac M-25 Series is a 2,500 CFM air filtration unit. It’s self-contained for use individually or in groups for your building or shop without exhausting or duct work required. Each M-25 is hand built in USA with industrial grade components housed in a heavy-duty 16 gauge steel cabinet and finished with chemical resistant powder coat paint.

The Air-Vac M-25 reduces the make-up air requirements up to 80% without any heat or A/C loss. Energy cost savings alone make your Air-Vac air cleaning system an attractive investment for small operations or large multi-unit installations.

*5 year warranty on parts excludes filters

m-25 with padding
m25 right air cleaner
m25 filter gauge and silencer kit

How It Works

First, the dirty air is pulled through the filter intake at the one end of the unit consisting of a 4 inch thick pre-filter to catch the large particles.

The second stage filtration process is an industrial grade 36 inch deep, 95% efficient bag filter which traps submicron particles that get through the pre-filter. The clean air exhausts back in the building out the back end.

Air Vac Unit Model M-25 Blueprint
M-25 Specs

Dimensions:24″×24″×59″

Weight: 160lbs

Power Consumption:
110v with 10ft power cord

Rated to Filter

Bondo Dust

Chemical Fumes

Diesel Smoke and Fumes

Grinding Dust

Dust

Light Paint Overspray

Lint

Oil Mist

Plastic Dust

Pollen

Printing Powder

Tobacco Smoke

Welding Smoke

Woodworking Dust

Other Smoke & Dust Problems

Options

Carbon Filter

Filter Change Gauge

Hepa Filter

Silencer: Reduces Sound by 12 Decibels

UV Filter

Washable Aluminum Mesh Pre-filter

Wrap Around Pre-filter
